ESP32 Networked Camera Node

A wireless camera node that automatically captures and saves images to a computer every 24 hours at random times. The ESP32 sleeps between captures to stay cool and save power.

Hardware

• ESP32S3 with Sense camera module
• OV5640 camera lens
• Micro SD card slot (included on Sense module)

Setup Notes

• Attach the antenna! The ESP32 needs it for WiFi
• Disable VPN on your computer during setup (blocks local network communication)

Software Architecture

Two-part system:

• ESP32 (Client) - Captures images and sends them over WiFi
• Python Server (Computer) - Receives and saves images

Part 1: Computer Setup (Python Server)

Install Python & Flask

Mac/Linux:

# Create project folder
cd Desktop
mkdir esp32_server
cd esp32_server

# Create virtual environment
python3 -m venv venv
source venv/bin/activate

# Install Flask
pip install flask

Create the Server

Create a file called image_server.py:

from flask import Flask, request
import os
from datetime import datetime

app = Flask(__name__)
SAVE_FOLDER = "esp32_images"

if not os.path.exists(SAVE_FOLDER):
    os.makedirs(SAVE_FOLDER)

@app.route('/upload', methods=['POST'])
def upload_image():
    try:
        filename = request.headers.get('X-Filename')
        if not filename:
            filename = f"image_{datetime.now().strftime('%Y%m%d_%H%M%S')}.jpg"

        filepath = os.path.join(SAVE_FOLDER, filename)
        with open(filepath, 'wb') as f:
            f.write(request.data)

        print(f"Image saved: {filename} ({len(request.data)} bytes)")
        return "Image received successfully", 200
    except Exception as e:
        print(f"Error: {e}")
        return "Error saving image", 500

if __name__ == '__main__':
    print("ESP32 Image Server")
    print(f"Saving to: {os.path.abspath(SAVE_FOLDER)}")
    app.run(host='0.0.0.0', port=8080, debug=False)

Run the Server

# Normal mode (terminal must stay open)
python3 image_server.py

# Background mode (can close terminal)
nohup python3 image_server.py > server.log 2>&1 &

Part 2: ESP32 Code

Arduino Libraries Needed

• WiFi.h
• WebServer.h
• HTTPClient.h
• esp_camera.h
• esp_sleep.h

Complete Code

Make sure to update:

• WiFi credentials (ssid and password)
• Server URL with your computer's IP address

#include <WiFi.h>
#include <HTTPClient.h>
#include "esp_camera.h"
#include "esp_sleep.h"
#include <time.h>

// WiFi credentials
const char* ssid = "YOUR_WIFI_NAME";
const char* password = "YOUR_WIFI_PASSWORD";

// Server URL - UPDATE WITH YOUR COMPUTER'S IP
const char* serverUrl = "http://192.168.1.100:8080/upload";

// XIAO ESP32S3 Sense camera pins
#define PWDN_GPIO_NUM     -1
#define RESET_GPIO_NUM    -1
#define XCLK_GPIO_NUM     10
#define SIOD_GPIO_NUM     40
#define SIOC_GPIO_NUM     39
#define Y9_GPIO_NUM       48
#define Y8_GPIO_NUM       11
#define Y7_GPIO_NUM       12
#define Y6_GPIO_NUM       14
#define Y5_GPIO_NUM       16
#define Y4_GPIO_NUM       18
#define Y3_GPIO_NUM       17
#define Y2_GPIO_NUM       15
#define VSYNC_GPIO_NUM    38
#define HREF_GPIO_NUM     47
#define PCLK_GPIO_NUM     13

// Sleep settings (hours)
#define MIN_SLEEP_HOURS 20
#define MAX_SLEEP_HOURS 24
#define uS_TO_S_FACTOR 1000000ULL

bool cameraInitialized = false;

void initCamera() {
  camera_config_t config;
  config.ledc_channel = LEDC_CHANNEL_0;
  config.ledc_timer = LEDC_TIMER_0;
  config.pin_d0 = Y2_GPIO_NUM;
  config.pin_d1 = Y3_GPIO_NUM;
  config.pin_d2 = Y4_GPIO_NUM;
  config.pin_d3 = Y5_GPIO_NUM;
  config.pin_d4 = Y6_GPIO_NUM;
  config.pin_d5 = Y7_GPIO_NUM;
  config.pin_d6 = Y8_GPIO_NUM;
  config.pin_d7 = Y9_GPIO_NUM;
  config.pin_xclk = XCLK_GPIO_NUM;
  config.pin_pclk = PCLK_GPIO_NUM;
  config.pin_vsync = VSYNC_GPIO_NUM;
  config.pin_href = HREF_GPIO_NUM;
  config.pin_sscb_sda = SIOD_GPIO_NUM;
  config.pin_sscb_scl = SIOC_GPIO_NUM;
  config.pin_pwdn = PWDN_GPIO_NUM;
  config.pin_reset = RESET_GPIO_NUM;
  config.xclk_freq_hz = 20000000;
  config.pixel_format = PIXFORMAT_JPEG;

  if(psramFound()){
    config.frame_size = FRAMESIZE_SVGA;
    config.jpeg_quality = 10;
    config.fb_count = 2;
  } else {
    config.frame_size = FRAMESIZE_QVGA;
    config.jpeg_quality = 12;
    config.fb_count = 1;
  }

  esp_err_t err = esp_camera_init(&config);
  cameraInitialized = (err == ESP_OK);
  if (cameraInitialized) {
    Serial.println("Camera initialized!");
  } else {
    Serial.println("Camera init failed");
  }
}

bool sendImageToComputer(camera_fb_t * fb) {
  HTTPClient http;
  http.begin(serverUrl);
  http.addHeader("Content-Type", "image/jpeg");

  time_t now = time(nullptr);
  struct tm* timeinfo = localtime(&now);
  char timestamp[32];
  strftime(timestamp, sizeof(timestamp), "%Y%m%d_%H%M%S", timeinfo);
  http.addHeader("X-Filename", String(timestamp) + ".jpg");

  int httpResponseCode = http.POST(fb->buf, fb->len);
  http.end();

  return (httpResponseCode > 0);
}

void captureAndSendImage() {
  // Take throwaway photo (camera sensor warm-up)
  camera_fb_t * fb_warmup = esp_camera_fb_get();
  if (fb_warmup) {
    esp_camera_fb_return(fb_warmup);
  }
  delay(1000);

  // Take real photo
  camera_fb_t * fb = esp_camera_fb_get();
  if (!fb) {
    Serial.println("Capture failed");
    return;
  }

  Serial.print("Photo captured: ");
  Serial.print(fb->len);
  Serial.println(" bytes");

  bool success = sendImageToComputer(fb);
  esp_camera_fb_return(fb);

  Serial.println(success ? "✓ Saved to computer" : "✗ Failed to save");
}

void setup() {
  Serial.begin(115200);
  Serial.println("\n=== ESP32 Camera Node ===");

  // Connect WiFi
  WiFi.begin(ssid, password);
  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }
  Serial.println("\nWiFi connected!");

  // Sync time
  configTime(0, 0, "pool.ntp.org");
  time_t now = time(nullptr);
  while (now < 8 * 3600 * 2) {
    delay(500);
    now = time(nullptr);
  }
  randomSeed(now);

  // Initialize camera
  initCamera();
  delay(2000);

  if (cameraInitialized) {
    captureAndSendImage();
  }

  // Sleep until next capture (random 20-24 hours)
  float randomHours = MIN_SLEEP_HOURS + (random(0, 1000) / 1000.0) * (MAX_SLEEP_HOURS - MIN_SLEEP_HOURS);
  uint64_t sleepSeconds = (uint64_t)(randomHours * 3600);

  Serial.print("Sleeping for ");
  Serial.print(randomHours);
  Serial.println(" hours");

  esp_sleep_enable_timer_wakeup(sleepSeconds * uS_TO_S_FACTOR);
  esp_deep_sleep_start();
}

void loop() {
  // Never runs - device sleeps and resets
}
